Meet the W-SQ Pro 18, designed to last a lifetime
Every W-SQ (Super Quiet) Pro 18 WhisperPower diesel generator is designed for non-stop, 1500/1800 rpm operation under harsh circumstances. They are robust, silent, compact and extremely reliable. All W-SQ Pro 18 generators are made in the Netherlands and tested during a 2 hours running period in one of the most advanced generator production facilities in the world, before distributed on a world-wide base by dedicated, service orientated, distribution partners.
Only the best 4 cylinder engines are applied: long lasting, reliable, silent engines, complying with EPA Tier 4 (USA standard) and Stage V (European standard). The engine is water-cooled and kept on a constant temperature via a heat exchanger.
Main Specifications: 1 or 3 Phase | 50 Hz (Stage V certified)
- Intermittent Power kW at 25°C (77°F)14.5 kW
- Continuous Power kVA at 25°C (77°F)17.5 kVA
- Nominal voltage / frequency1 Phase | 230 VAC | 50 Hz
- Nominal voltage / frequency3 Phase | 230/400 VAC | 50 Hz
- Rpm range1500 rpm
- EngineWhisperPower Kubota V2203 M BG - 4 cylinder
- Emission classEPA + Stage V certified
- Noise level55 dB
- Length x width x height, mm (in.)1220 x 718 x 754 (48 x 28.3 x 29.7)
- Dry weight (cabinet + PMG), kg (lb.)495 (1091)
All specifications: 1 or 3 Phase | 50 Hz (Stage V certified)
| ARTICLE NUMBER | |
|---|---|
| 41208120-STV | W-SQ Pro 18 - 1 Phase | 230 VAC | 50 Hz | STV |
| 41208320-STV | W-SQ Pro 18 - 3 Phase | 230/400 VAC | 50 Hz | STV |
| MAIN SPECIFICATIONS | |
|---|---|
| Intermittent Power kW at 25ºC (77ºF) | 14.5 kW |
| Continuous Power kVA at 25ºC (77ºF) | 17.5 kVA |
| Noise level | 55 dB |
| Rpm range | 1500 rpm |
| Cooling | External radiator cooling |
| Alternator voltage regulation | AVR, forced ventilation |
| Peak power 2 s | 200% |
| Harmonic distortion | < 3% |
| Frequency tolerance | +/- 5 % |
| DIESEL ENGINE SPECIFICATIONS | |
|---|---|
| Engine | WhisperPower Kubota V2203 M BG |
| Emission class | EPA + Stage V certified |
| Cylinders | 4 |
| Displacement, L (in.) | 2.197 (134) |
| Bore, mm (in.) | 87 (3.4) |
| Store, mm (in.) | 92,4 (3.6) |
| Compression ratio | 22.0 |
| Combustion system | IDI |
| Nominal speed, rpm | 1500 |
| Net Continuous power at rated rpm, kW (hp) | 17.2 (23.1) |
| Governor, type | Mechanical (+/- 5%) |
| Angular operation continuous | 20º |
| DIMENSIONS & WEIGHT | |
|---|---|
| Length x width x height (cabinet), mm (in.) | 1220 x 718 x 754 (48 x 28.3 x 29.7) |
| Dry weight, kg (lb.) | 495 (1091) |
| Dry exhaust | Ø 1.5 inch BSP |
| Oil dipstick | Top & side |
| Max. operating angle | 25º in all directions |
Main Specifications: 1 or 3 Phase | 50 Hz
- Intermittent Power kW at 25°C (77°F)16.5 kW
- Continuous Power kVA at 25°C (77°F)20 kVA
- Nominal voltage / frequency1 Phase | 230 VAC | 50 Hz
- Nominal voltage / frequency3 Phase | 230/400 VAC | 50 Hz
- Rpm range1500 rpm
- EngineWhisperPower Kubota V2203 M BG - 4 cylinder
- Noise level55 dB
- Length x width x height, mm (in.)1220 x 718 x 754 (48 x 28.3 x 29.7)
- Dry weight (cabinet + PMG), kg (lb.)495 (1091)
All specifications: 1 or 3 Phase | 50 Hz
| ARTICLE NUMBER | |
|---|---|
| 41208120 | W-SQ 18 Pro - 1 Phase | 230 VAC | 50 Hz |
| 41208320 | W-SQ 18 Pro - 3 Phase | 230/400 VAC | 50 Hz |
| MAIN SPECIFICATIONS | |
|---|---|
| Intermittent Power kW at 25ºC (77ºF) | 16.5 kW |
| Continuous Power kVA at 25ºC (77ºF) | 20 kVA |
| Noise level | 55 dB |
| Rpm range | 1500 rpm |
| Cooling | external radiator cooled |
| Alternator voltage regulation | AVR, forced ventilation |
| Peak power 2 s | 200% |
| Harmonic distortion | < 3% |
| Frequency tolerance | +/- 5 % |
| DIESEL ENGINE SPECIFICATIONS | |
|---|---|
| Engine | WhisperPower Kubota V2203 M BG |
| Cylinders | 4 |
| Displacement, L (in.) | 2.197 (134) |
| Bore, mm (in.) | 87 (3.4) |
| Store, mm (in.) | 92,4 (3.6) |
| Compression ratio | 22.0 |
| Combustion system | IDI |
| Nominal speed, rpm | 1500 |
| Net Continuous power at rated rpm, kW (hp) | 17.2 (23.1) |
| Governor, type | Mechanical (+/- 5%) |
| Angular operation continuous | 20º |
| DIMENSIONS & WEIGHT | |
|---|---|
| Length x width x height (cabinet), mm (in.) | 1220 x 718 x 754 (48 x 28.3 x 29.7) |
| Dry weight, kg (lb.) | 495 (1091) |
| Dry exhaust | Ø 1.5 inch BSP |
| Oil dipstick | Top & side |
| Max. operating angle | 25º in all directions |
Main Specifications: Split Phase or 3 Phase | 60 Hz
- Intermittent Power kW at 25°C (77°F)16.5 kW
- Continuous Power kVA at 25°C (77°F)20 kVA
- Nominal voltage / frequencySplit Phase | 120/240 VAC | 60 Hz
- Nominal voltage / frequency3 Phase | 120/208 VAC | 60 Hz
- Rpm range1800 rpm
- EngineWhisperPower Kubota V2203 M BG - 4 cylinder
- Noise level55 dB
- Length x width x height, mm (in.)1220 x 718 x 754 (48 x 28.3 x 29.7)
- Dry weight (cabinet + PMG), kg (lb.)495 (1091)
All specifications: Split Phase or 3 Phase | 60 Hz
| ARTICLE NUMBER | |
|---|---|
| 41208125 | W-SQ Pro 18 - Split Phase | 120/240 VAC | 60 Hz |
| 41208325 | W-SQ Pro 18 - 3 Phase | 120/208 VAC | 60 Hz |
| MAIN SPECIFICATIONS | |
|---|---|
| Intermittent Power kW at 25ºC (77ºF) | 16.5 kW |
| Continuous Power kVA at 25ºC (77ºF) | 20 kVA |
| Noise level | 55 dB |
| Rpm range | 1800 rpm |
| Cooling | External radiator cooled |
| Alternator voltage regulation | AVR, forced ventilation |
| Peak power 2 s | 200% |
| Harmonic distortion | < 3% |
| Frequency tolerance | +/- 5 % |
| DIESEL ENGINE SPECIFICATIONS | |
|---|---|
| Engine | WhisperPower Kubota V2203 M BG |
| Cylinders | 4 |
| Displacement, L (in.) | 2.197 (134) |
| Bore, mm (in.) | 87 (3.4) |
| Store, mm (in.) | 92,4 (3.6) |
| Compression ratio | 22.0 |
| Combustion system | IDI |
| Nominal speed, rpm | 1800 |
| Net Continuous power at rated rpm, kW (hp) | 17.2 (23.1) |
| Governor, type | Mechanical (+/- 5%) |
| Angular operation continuous | 20º |
| DIMENSIONS & WEIGHT | |
|---|---|
| Length x width x height (cabinet), mm (in.) | 1220 x 718 x 754 (48 x 28.3 x 29.7) |
| Dry weight, kg (lb.) | 495 (1091) |
| Dry exhaust | Ø 1.5 inch BSP |
| Oil dipstick | Top & side |
| Max. operating angle | 25º in all directions |
Downloads
English
Deutsch
English
English
English
English
English
English
English
English
English
English
Español
简体中文 Optional installation parts
Spare parts
Optimal Sound reduction
The W-SQ Pro 18 comes standard with a robust sound-shield with corrosion proof metal plating and heavy insulation material for optimal sound reduction. The sound shield is equipped with easy entry to all sides of the generator and offers access to all maintenance related components from one-side.
Units can also be delivered without a sound-shield. Ask for our open units with or without sound-shield.
7" Touch screen and DeepSea control
Important feature of our new SQ Pro range is the 7 inch full colour touch screen control which will be connected with WhisperCare. This allows full control over the W-SQ Pro 18 generator system. A perfect solution for instant information and/or historic with attractive visualization.
Features DeepSea control
- Genset parallel functionality included (ask for more details)
- Provides secure and simple off site monitoring (optional)
- Enables fault conditions to be resolved quickly and provides instant system information to aid preventative maintenance
- Graphical displays showing, charts, meters, power display, graphs and engine status information
- Information is displayed clearly and in a universal format for all users
- Language by choice
Pure power, excellent service & adequate parts supply
All W-SQ Pro 18 generators are set up to automatically operate air-conditioning/ heating systems, heavy-duty tools, compressors, kitchen galleys, lights, refrigeration and cooling systems, computers and more. All at the same time, depending on the load.
The ever growing global network of distributors and dealers take care of technical support and service. Spare parts can be ordered from them or through whisperpower.com.
1 or 3 phase | 50 Hz | Stage V
Fixed speed 1500 rpm
1 or 3 Phase | 50 Hz
Fixed speed 1500 rpm
Split Phase or 3 Phase | 60 Hz
Fixed speed 1800 rpm
24/7 Monitoring with WhisperCare 2.0
The W-SQ Pro 18 can be monitored 24/7 in real-time remotely via the optional WhisperCare Wi-Fi router package. This is based on a 4G/ 5G internet connection in combination with a WhisperTouch 7ʺ or 10” monitoring screen.
With WhisperCare, all important parameters can be read from a distance via a cell phone, tablet or computer. In addition, full Wi-Fi is now available for computers, TVs and other enabled devices. WhisperPower systems can also be connected to various digital switching systems and each integrates perfectly with Naviop, Yachtcontrol, Garmin, Trigentic, EmpirBus and others.
Advanced total system
- Manufactured in Holland, Highest quality standards
- Robust AVR voltage regulation
- Electronic governor for best power quality
- Air-cooled, industrial back-end
- Indirect water cooling principle
- All connections are pre-mounted (cooling, exhaust, electrical)
- Parallel connection optional
- Ungrounded versions available
- Deep Sea controls available
- Open versions, units without sound shields, available
